Handheld Smart Full-Color Portable 3D Laser Scanner With 0.1 Mm RESOLUTION

Product Categories
DongGuan Sinowon Precision Instrument Co., Ltd. （2）
Contact Now

Handheld Smart Full-Color Portable 3D Laser Scanner With 0.1 Mm RESOLUTION

  • 1
  • 2
  • 3

Brand Name : Sinowon

Model Number : FIXED

Certification : CE

Place of Origin : CHINA

MOQ : 1 set

Price : Negotiate

Payment Terms : L/C, T/T, Western Union

Supply Ability : 30 sets per month

Delivery Time : 15 days

Packaging Details : carton

ACCURACY : up to 0.1 mm

REFERENCE DISTANCE : 400 mm

DEPTH OF FIELD : 200 mm

SINGLE SCANNING AREA : 250 × 185 mm

LIGHT SOURCE : White light (LED)

SYSTEM SUPPORT : Win7, ,Win10, 64 bit

Contact Now

Smart full-color handheld 3D scanner , FIXED

  • Product Feature
  1. Quickly acquire colorful 3D data of real objects with high precision.Non-contact scanning
  2. No need to stick any positioning targets, color matching the 3D data automatically.
  3. Easy to carry and multi-function scanning provides you with a wise choice of 3D digitized solution.

  • Application

​ Handheld Smart Full-Color Portable 3D Laser Scanner With 0.1 Mm RESOLUTION Handheld Smart Full-Color Portable 3D Laser Scanner With 0.1 Mm RESOLUTION

  • Specifications

SCAN MODE FIXED
PROJECTION MODE Raster Projection
ACCURACY up to 0.05 mm
VOLUME ACCURACY Not applicable
MEASURING RATE Single scan time＜2s
RESOLUTION 0.1 mm
RECOMMENDED OBJECT SIZE 0.03 - 0.25 m
REFERENCE DISTANCE 400 mm
DEPTH OF FIELD 200 mm
SINGLE SCANNING AREA 250 × 185 mm
LIGHT SOURCE White light (LED)
TEXTURE MAPPING ACCURACY 1 Pixel
CONNECTION STANDARD USB 3.0
SYSTEM SUPPORT Win7, ,Win10, 64 bit
WEIGHT 0.65 kg
DIMENSIONS 250 × 140 × 50 mm
OPERATING TEMPERATURE RANGE 0 - 40 °C
OPERATING HUMIDITY RANGE 10 - 90 %
OUTPUT FORMATS .stl, .obj, .wrl, .ply, .txt, . xyz, .asc etc., Customizable
COMPATIBLE SOFTWARE 3DSystem (Geomagic Solutions), InnovMetric Software (PolyWorks),Dassault Systemes (CATIAVS and SolidWorks),PTC (Pro/ENGINEER),Siemens (NX and Solid Edge),Autoesk (Inventor,Alias,3ds Max,Maya,Softimage)

More details can be found (PDF) : Smart full-color handheld 3D scanner.pdf
